Flame Cutting

Flame Cutting – (Oxy Fuel)

Oxy fuel cutting is a process which has been around for over 100 years. However, it’s still widely utilised today, and it’s still a very important aspect and technology of many industries.

Oxy fuel cutting use a combination of fuel gases and oxygen to cut metals. A variety of different fuels may be utilised, although the most common is acetylene. Other gases utilised include natural gas, propane, hydrogen, propylene, liquefied petroleum gas (LPG), and combinations of these gases. Oxy-fuel cutting begins by using a torch to heat a metal to its kindling temperature.

This is the lowest temperature at which the metal in question will spontaneously ignite. At this point, a stream of oxygen is trained onto the metal, in turn burning it into a metal oxide. This new metal oxide then flows out and away from the intact material being utilised. Any leftover slag can be wiped or tapped away. It’s actually the heat produced by the metal oxide and its contact with the rest of the material which actively continues the cutting process. The torch itself only heats the metal to begin the process.

---

Capacity:

• We have 4 CNC Oxy-propane flame profiling machines.
• Each is digitally connected to our CAD/CAM systems. They have 5 heads per machine and are capable of cutting profiles up to 6,000mm x 3,00mm. Various thicknesses of steel plate are available from 5mm to 300mm in grades S275/43A, S355/50B and EN8.
• We can work from simple sketches, engineering drawings or electronic DXF files. We can also reverse engineer existing jobs using our magic eye scanner.

For more information about our CNC flame cutting, CNC profile cutting or Lumsden grinding services, contact Patrick Steel Ltd today on: 02476 645 422 /
